High-tech features in a solid package. A purpose-built ADA-certified wheelchair scale delivering hospital-grade durability, advanced motion filtering, and seamless EMR connectivity.
Built to exceed accessibility expectations, the DS9100-ADA combines ADA-compliant design with advanced clinical weighing technology.
The scale’s extra-wide, low-profile platform and ramp-assisted entry support safe wheelchair access, while its 1000 lb capacity and multi-point calibration capability ensure clinical-grade accuracy. Motion compensation technology improves workflow efficiency, reducing wait time for stable readings.
Integrated USB, RS-232, and WiFi communication options allow compatibility with leading EMR systems, making the DS9100-ADA an ideal solution for hospitals and medical facilities seeking accessibility without sacrificing performance.
Specifications
| Warranty: | Three Years |
| Power: | AC Adapter (Included) 100-240VAC, 50/60HZ ULc, ULus, CE 6 AA batteries NOT included |
| Battery Life: | One Year |
| Weight Capacity: | 1000 x 0.1 lb (454 x 0.05 kg) |
| Construction: | Aluminum and Painted Steel with Plastic Trim |
| Dimensions: | Resting on Feet Weighing Platform: 40.1" W x 36.1" D x 2.5" H Two Ramps Extended : 87.6" W x 45.3" D x 46.7" H Two Ramps Folded: 43.8" W x 45.3" D x 46.7" H Transport and Storage Ramps and Column Folded Standing on Casters: 43.8" W x 15.7" D x 45.3" H |
| Display: | 1" High LCD |
| Units: | lb, kg, Units Lock feature |
| Controls: | Zero, LB, KG, Last Weight, Reweigh, BMI, Full Keypad, Chair Recall, Enter |
| BMI Calculator: | Input data in FT/IN or CM |
Options
| Options: | RS-232 Communications Port USB Communications Port US AC Adapter (Part#: XFR0082) International Transformer (Part#: Varies With Region) 180 degree Indicator Rotation |
